REVI BIKES Rebel.2

REVI BIKES Rebel.2: The Ultimate Folding Commuter E-Bike

Meet the REVI BIKES Rebel.2, a truly versatile electric bike designed for modern life. This innovative e-bike is more than just a commuter; it’s a solution for families, a dependable cargo hauler, and a compact traveler all in one. The Rebel.2's powerful performance, folding design, and family-friendly features make it the perfect companion for navigating city streets, running errands, or embarking on a weekend adventure.

Specs

• Motor: 48V 750W
• Motor Peak Output: 1000W
• Battery Cell: Samsung （UL 2849）Battery Type: Lithium-ion
• Battery Capacity: 48V 15AH
• Max Range: 60 Miles
• Charging Time: 4 - 6 Hrs
• Front Light: Included
• Pedal Assist: 1-5 levels
• Brake: F/R Hydraulic Brake
• Rotors: 180mm Front and Rear
• Fork: Suspension Fork
• Wheel Size: 20" X 3.0"
• Display: Full Color with USB Port
• Display Function: PAS Level, Current Speed, Max Speed, Odometer, Trip, Daylight and Night Model Selection, Class 1,2,3 model selection
• Frame Material: 6061 Aluminum Alloy
• Shift: SHIMANO™ 7 Speed
• Crank Wheel: 52T 170mm
• Saddle: Leather
• Chain: EPT Anti-Rust
• Sensor: Cadence

Speed & Range

*A 120-lb rider using PAS 1 in Eco mode on flat roads.

Class: 1/2/3

Default Speed: 20 MPH

Top Speed: 28 MPH

Pedal Assist Range: 60 Miles

Weight & Load

• Weight: 65lbs with battery
• Payload Capacity: 400Ibs
• Rear Cargo Capacity: 120lbs

Package Included

Tutorial Video

Bike Assembly

Introduce & Speed Test
